The BR2 is an affordable, ruggedized mobility router equipped with dual cellular modems. It serves as an all-in-one WAN solution for industrial deployments, featuring a GE WAN port, Wi-Fi WAN, USB WAN, and dual cellular connectivity. Additionally, it provides 4 LAN ports for wired device connectivity to the internet. The device offers flexible power and port options, including a 4-pin Molex Micro-Fit power port, terminal power port, and PoE Input port. The BR2 also features GPS, GPIO, and Ignition Sensing capabilities that are useful for mobile and industrial applications.
- WAN Interface: 1x 10/100/1000M Ethernet, 2x Embedded Cellular Modems with Redundant SIM Slots, 1x USB Interface
- LAN Interface: 4x 10/100/1000M Ethernet
- Wi-Fi Interface: Simultaneous Dual-Band (2.4GHz / 5GHz) Wi-Fi 5, 2×2 MIMO, Wi-Fi WAN and/or AP
- SpeedFusion Features: Hot Failover, WAN Smoothing, Bandwidth Bonding*
- Router Throughput: 300Mbps
- Cellular Data Rate: CAT-4: 150 Mbps / 50 Mbps
- InControl Remote Management
- Use Cases: ATMs, Point of Sale, Vending Machine, Automated Fare Collection
*Requires PrimeCare Subscription.
